Daikin 4 Ton G/E 115,000 BTU/Hr Packaged Rooftop Unit | 208-230/3
- Price includes installation
- Free shipping within the GTA
$12,728.00 + HST
Next Day Installation
Free Shipping
Financing Available
Description
The 4T DBG0483CH00001F Gas/Electric 115MBTU Packaged Rooftop with High Static Belt Drive is Built to Perform with Features that Help Provide Low Installation and Operation Costs, Superior Indoor Quality, Efficient Operation and Longevity
Specifications
| Specification | Detail |
|---|---|
| Brand | Daikin |
| Efficiency (AFUE) | 80% |
| Energy Efficiency Rating (EER) | 11-1/2 |
| Height (In.) | 39-7/8 |
| Length (In.) | 74 |
| Refrigerant | R410A |
| Weight (lbs) | 644 |
| Width (In.) | 48-5/16 |
| Manufacturer | Daikin |
| Nominal Cooling Capacity (Tons) | 4 |
| Blower Motor Design | High Static Belt Drive |
| Stages of Cooling | 1 Stage |
| Factory Installed Economizer | Not Included |
| AFUE Rating | 80% |
| Cabinet Material | Galvanized Steel |
| Compressor Design | Scroll |
| Cooling Capacity (Btu/Hr) | 48,000 |
| Energy Efficiency Rating (SEER) | 14 |
| Entering Air Temperature (EAT) Dry Bulb | 80 °F |
| Entering Air Temperature (EAT) Wet Bulb | 67 °F |
| External Static Pressure (In. WC) | 0.6 |
| Flow Configuration | Downflow |
| Gas Heating Type | High Heating Range |
| Heat Exchanger Material | Aluminized |
| Heating Capacity (Btu/Hr) | 115,000 |
| Hertz | 60 Hz |
| Leaving Air Temperature (LAT) Dry Bulb | 59.7 °F |
| Leaving Air Temperature (LAT) Wet Bulb | 57.5 °F |
| Maximum Fuse Amps | 35.00/35.00 A |
| Minimum Circuit Ampacity | 22.60/22.60 A |
| Net Cooling Capacity (Btu/Hr) | 47,051 |
| Nominal Filter Size (In.) | (2) 20 × 25 × 2 |
| Options Included | Filter Drier, High Pressure Switch, Low Pressure Switch |
| Outdoor Design Temperature | 95 °F |
| Sensible Cooling Capacity (Btu/Hr) | 35,761 |
| Total External Static Pressure (In. WC) | 0.67 |
| Voltage (V) | 208-230/3 |
